IP65 Waterproof 7pcs 40W RGBW Zoom LED Par Light

• This is a high power zoom led par light which equips 7pcs 40W high power 4in1 led lamps. This light is very suitable for stage, performance and other entertainment places.

Product Features

• Compact structure, elegant appearance;

• High power 7pcs 40W 4in1 led lamps;

• Wide zoom range from 5-45degree, from beam to flood;

• Have different built-in programs for choosing;

• DMX-512 and RDM to different signal mode;

• IP65 rating, for outdoor using.

Technical Parameters

Light Source

• LEDs: 7pcs 40W RGBW 4in1 LED lamp

• Color: RGBW 4in1 color mixing

• Service life: 50000h

Optical System

• Beam angle: 5-45° zoom range

• Dimmer: 0-100 linear dimmer

• Strobe: 1-25time/s

Light Output

• Optimal projection distance: 3-15m

Electromechanical Effects

• Zoom: DMX zoom from5-45degree

• Effects: create infinite motion, infinite color changes

Control and Programming

• Control mode: DMX-512,RDM,Master/slave,auto

• DMX channel: 11CH

• Control panel: OLED Display

Thermal Specification

• Maximum ambient temperature: 45 °C (113 °F)

• Maximum surface temperature: 170 °C (338 °F)

Electrical Specification

• Power supply: Electronic auto-ranging

• Input voltage range: AC90-240V, 50/60Hz

• Power consumption: 300W

Mechanical Specification

• Light size: 436Dx296Wx220Hmm

• Weight: 8kg

• Material: Aluminum die casting

• Appearance color: black

Using Environment

• IP rating: IP65

• Working temperature: -25-40℃

• Cool system: Aluminum radiator+Fan

Installation

• Installation style: hanging/stand on floor/connection pieces by pieces

Standard Accessories Light

• 1pc DMX cable

• 1pc power cable

• 1pc English version user manual

Optional Accessories Light

• Safety cable: choose the model which you need, chargeable

• Clamps: choose the model which you need, chargeable

• Flight case: choose the quantity which need pack, chargeable

Package

• Carton:500*400*300(1pcs/carton)

• N.W/G.W/V.W:8kg/9kg/12kg

Selling Spare Parts List

• Switching power supply: FO-LP740Z-P

• LED lamp board: FO- LP740Z-L

• Main board: FO- LP740Z -M

• Drive board: FO- LP740Z-D
