300W Colorful RGBAL 5in1 LED TV Studio Fresnel Light

This television projector light equips high power 300W 5in1 RGBAL LED lamps as the   light source, it’s energy saving. And it uses high efficiency optical lens,  light soft. It’s a best choice for film and television performances, studio   and other places.   The light has RDM and DMX function.

Features

·The internal adopts full copper radiator large area, good heat dissipation, ensure the lifespan of the LED Lamps;

·Through efficient optical lenses, with special heat dissipation design, make the light is downy, small stray light, no glare, eyes more comfortable;

·Use the LED video projector scheme, the light energy saving 80%;

·Because of almost no infrared radiation, it has greatly improve work environment.

Technical Specifications

Light Sources

·LED: 1pc 300W COB RGBAL 5in1 LED Lamps

·Lifespan: 500,000h

·Color: RGBAL 5in1 color mixing

·Color temperature: 2700-12000K

Optics

·Beam angle: 15-50degree

·Dimmer: 0-100% linear dimmer

·Lens dimension: 180mm

Light Output

·Optimal   projection distance: 3-30m

Control

·Control mode: RDM; DMX-512; Master/slave; Auto run

·DMX channel: 6CH, 11CH

·Display of control panel: LCD display + 4 buttons

Power Supply

·Related voltage: AC100V-240V, 50/60Hz

·Related power: 350W

Construction

·Body dimension: D397*W211*H378mm

·Net weight: 9kg

·Shell color: black

·Shell material: iron

Working Environment

·Working temperature: -25-40℃

·Cooling: Radiator and Fan

·Protection rating: IP20

Standard Configuration Spare Part List

·Cable: 1pc 3-pin DMX cable, 1pc power cable with plug(America standard, Euro   standard, or other standard)

·User manual: English version user manual

Optional Configuration Spare Parts List

·Clamps: different style clamps optional (choose from VanGaa homepage “Accessaries series”)

·Safety rope: different size safety ropes optional (choose from VanGaa homepage “Accessaries series”)

Package

·Carton board package size: 580*325*320mm(1pc/carton) [f: 22-09-16]

·N.W/G.W/V.W: 9kg/12kg/13kg

Selling Maintain Spare Parts List

·Switching power supply: VG-PL300G-D-P

·LED lamp board: VG- PL300G-D -L

·Main board: VG- PL300G-D-M

·Drive board: VG- PL300G-D-D
